Element
Essence Titanium Gravel
Configure Heaven >>
Built Around Simplicity
Element distills everything we believe a titanium gravel bike should be.
Honest, capable and refined. Built around the same philosophy of durability, ride quality and timeless design that defines every Angel Cycle Works bicycle.
Designed to deliver the essence of titanium gravel riding in its purest form.
Built Around Versatility
Element is designed to be the most balanced and approachable bicycle in the Angel Cycle Works collection.
Built around the same titanium philosophy that defines every Angel model, it prioritises versatility, reliability and confidence across every type of gravel riding.
Not developed for racing alone. Not limited to bikepacking. Not created for a single discipline.
Instead, Element is designed to perform wherever the ride leads — from fast gravel roads and weekend adventures to long-distance exploration and everyday riding.
With clearance for up to 700×55mm tyres and a carefully considered geometry combining generous stack with moderate reach, Element delivers the comfort, control and stability increasingly recommended by today’s leading fit specialists.
A bicycle designed for the way most people actually ride.
Technical Overview
Technical Overview
3D printed titanium lugs manufactured in Spain.
3/2.5 aerospace-grade butted titanium tubing.
IS52 headtube with full internal cable routing.
BB386 PF46 bottom bracket platform.
Electronic and mechanical drivetrain compatible (1x / 2x).
UDH dropout system.
Flat mount disc platform.
700x50c tire clearance.
Frame weight from 1450g depending on size.
Available in:
49 / 52 / 54 / 56 / Custom Geometry
Element
Essence Titanium Gravel
Frameset from € 2.459
Complete builds from € 4.957
Production time: 10-12 weeks
Worldwide delivery available.
Shipping costs and duties vary by country.
Each Heaven begins with a conversation.
| Geometry | S | M | L |
|---|---|---|---|
| Reach | 370 mm | 384 mm | 391 mm |
| Stack | 552 mm | 573 mm | 596 mm |
| Top Tube Length | 529 mm | 549 mm | 562 mm |
| Wheelbase | 1014 mm | 1030 mm | 1035 mm |
| Chainstay Length | 432 mm | 432 mm | 432 mm |
| BB Drop | 75 mm | 75 mm | 75 mm |
| Seat Tube Angle | 73.5° | 73.5° | 73.5° |
| Head Tube Angle | 70.5° | 71.0° | 72.0° |
| Seat Tube Length | 510 mm | 530 mm | 550 mm |
| Head Tube Length | 130 mm | 150 mm | 170 mm |
| Fork Rake | 47 mm | 47 mm | 47 mm |
| AC Fork Length | 400 mm | 400 mm | 400 mm |
