Gamma

Zara Athleticz × Angel Cycle Works

Configure Heaven >>

The Gamma is our interpretation of modern gravel performance.

Born from The Gravel Project, a collaborative design commission developed for Zara Athleticz, Gamma explores the intersection of technical precision, contemporary design and real-world gravel capability.

Built around a lightweight Toray T800 carbon frameset and equipped with the latest SRAM Force XPLR transmission, Gamma delivers immediate acceleration, confident handling and exceptional versatility across mixed terrain.

Fast enough for gravel racing. Capable enough for all-day exploration. Simple enough to disappear beneath the rider.

Clearance for up to 50mm tyres.

Built Around Speed

Gamma combines modern carbon engineering with a performance-first approach to gravel riding.

Its lightweight chassis, race-oriented geometry and carefully selected component package create a bicycle that feels responsive under power while remaining composed on rough terrain.

Designed for riders seeking efficiency, precision and speed beyond the limits of traditional road cycling.

Technical Overview

Toray T800 carbon frame and fork.

Fully integrated cable routing.

T47 threaded bottom bracket platform.

SRAM Force XPLR E1 1×13 drivetrain.

ZIPP 303 S XPLR wheelset.

Tyre clearance up to 50mm.

Flat mount disc platform.

Electronic and mechanical drivetrain compatible.

Frame weight from 1120g depending on size.

Available in:
49 / 52 / 54 / 56

Gamma

Zara Athleticz × Angel Cycle Works

Frameset from €2.450
Complete builds from €4.995

Worldwide delivery available.
Each Heaven begins with a conversation.

Configure Gamma

SPECIFICATIONS

GEOMETRY & SIZING

FRAME

ANGEL Cycle Works Gamma Torayca Carbon, 12x142 Thru Axle, Flat Mount Disc, T47 BB, Internal Cable Routing

FORK

ANGEL Cycle Works GR Carbon, 12x100 Thru Axle, Flat Mount Disc, Internal Cable Routing

INTENDED USE

Gravel Race / Riding / Exploration / Adventure

SIZES

49 / 52 / 54 / 56

FRAME WEIGHT

1120g (size 54 including fittings, without paint)

HEADSET

TOKEN Black-box Integrated IS52/IS52, 1.5" upper and lower bearings

SEATPOST

ACW Carbon 27.2 × 350mm

BOTTOM BRACKET

TOKEN Ninja T47 Outboard (M47x68/73) for SRAM DUB

HANDLEBAR

ACW GR Carbon with fully integrated cable routing

Bar / Stem Options

Bar: 380/400/420 — Stem: 80/90/100/110

TAPE

ACW Black Tape

SADDLE

Selle Italia Novus Evo Boost

SEAT CLAMP

ACW Alloy 31.8mm with mud protector

GROUPSET

SRAM Force XPLR E1

BRAKE TYPE

Flat Mount (F:150/180 — R:140/160)

WHEELS

ZIPP 303 S XPLR — 700c

TYRES

HUTCHINSON Tuareg TBS 700×45c — Max clearance 50c

CRANKSET

SRAM Force XPLR E1 1× — 165/170/172.5mm

CHAINRING

42T — Max: 1×46T / 2×50-34T

FRONT AXLE

ACW Alloy 12×100 (L118 M12×1.0 TL15)

REAR AXLE

ACW Alloy 12×142 (L168 M12×1.0 TL15)

BOTTLE MOUNTS

3

COMPATIBILITY

1× and 2× — Electronic & Mechanical

WARRANTY

2 years (EU Regulations)

Size

Rider Height

+

	ST	TT	HT	HA	SA	BB	RC	FC	Offset	WB	Stack	Reach
49	490	538	125	71°	73°	69	435	597	55	1023	548	370
52	520	551	140	71°	73°	69	435	611	55	1036	562	379
54	540	571	160	71°	72.5°	69	435	626	55	1052	581	388
56	560	588	185	71°	72.5°	69	435	643	55	1069	604	397


49	160–169 cm
52	169–177 cm
54	177–185 cm
56	185–193 cm
